ascMclaren Specifications

I weighed the Capri on 6-7-12 and the actual weight came in at 3438lbs. A bit hefty but with the role bar and additional chassis bracing it makes sense!

Engine

  • 11.1 347 Stroker Bullet (balanced/blueprinted)
  • EAGLE forged stroker crank and rods
  • JE forged nitrous pistons
  • ARP hardware throughout
  • FRPP heavy duty oil pump
  • AFR 185 Aluminum heads (2.02/1.60″ valves)
  • FelPro MLS head gaskets
  • Comp Cams 1.6 roller rockers and titanium retainers
  • Comp Cams custom cam
  • Moroso high capacity oil pan and pickup

Intake

  • Edelbrock Victor EFI intake
  • 90mm Accufab throttle body
  • 80mm Pro-M mass air meter (No mass air meter – Running speed density now – as of 6-16-11)
  • Anderson Ford’s 4″ N/A Powerpipe
  • K&N conical filter

Exhaust - NEW for 2012

  • MAC Jet Hot coated 1-3/4″ shorty headers
  • Bassani 2.5″ stainless steel X-pipe
  • 2.5″ Dynomax VT Mufflers (17959)
  • 2.5″ American Muscle Stainless Steel Flow Tubes
  • 2.5″ American Muscle Stainless Steel Tailpipes

Fuel

  • Kirban adjustable fuel pressure regulator
  • Auto Meter pillar mounted fuel pressure gauge
  • Holley 255 lph in-tank HV fuel pump
  • FRPP 60# injectors

Ignition

  • Crane Hi-6Tr Ignition (w/timing retard) (No longer using – converted car to Coil on Plug)
  • Performance Distributors 5.0 Dyna-Mod power module (No longer using – converted car to Coil on Plug)
  • Performance Distributors Screamin’ Demon Coil (No longer using – converted car to Coil on Plug)
  • Performance Distributors 5.0 brass cap and rotor (No longer using – converted car to Coil on Plug)
  • MSD Billet Aluminum distributor
  • 8 Individual Smart Coils
  • Magnacore custom wires
  • Autolite 3923’s (.050 gap)

Driveline

  • Tremec TKO-600 transmission
  • Pro-5.0 Power Tower shifter w/deluxe handle
  • Spec Stage III+ Clutch (w/lightened pressure plate)
  • Spec Billet Aluminum Flywheel
  • McLeod steel safety blow-proof bellhousing
  • Steeda adjustable clutch cable, quadrant and firewall adjuster
  • Lakewood driveshaft safety loop

Rear

  • FRPP 4.10:1 gears
  • Ford Racing HD carrier
  • Moser 31 Spline hardened axels
  • T/A heavy duty rear girdle

Suspension

  • Eibach drag launch kit (w airbag) in the rear only since going to coil overs
  • Maximum motorsport Coil over kit (front coil overs only) w/ Koni Double Adjustable Shocks and stuts all around
  • Maximum Motorsports caster/camber plates
  • Steeda HD billet aluminum weight jacker rear lower control arms
  • Steeda HD adjustable upper control arms

Chassis

  • Kenny Brown Double cross sub-frame connectors (welded)
  • 6-point owner installed S&W roll bar
  • Wild Rides lower torque box repair kit
  • Wild Rides S-box upper torque box replacement

Brakes

  • Baer Sport Kit Front Brakes
  • 12.5″ vented/cross drilled/zinc washed front rotors
  • 2 piston PBR calipers
  • HD Lines
  • HD Brodix master cylinder

Misc

  • Be-Cool Aluminum Radiator
  • Professional Products SFI harmonic balancer
  • FRPP underdrive pulleys
  • P/A 130 amp alternator
  • P/A Mini Starter
  • Hurst Line Loc
  • Stinger-Performance’s Plug-in Microsquirt Powered (PiMPxs) ecu with Coil On Plug conversion kit

Interior

  • Ford Mustang Bullitt Pedals
  • Autometer, fuel pressure and nitrous pressure gauges
  • Hidden shift and line loc lights
  • Custom upholstered rollbar
  • Pioneer DEH-4300UB Head Unit
  • Sony 30×2 Amplifier
  • 10″ Amplified Bazooka Tube
  • Kicker Impulse component speakers throughout

Nitrous

  • Compucar Adjustable Nitrous Kit (50,90,125,150 hp)
  • Compucar full throttle activated micro-switch
  • Compucar purge valve
  • Nitrous Oxide Systems Bottle blanket (bottle heater)
  • Autometer Pillar mounted pressure gauge
  • Full throttle activated timing retard
  • Custom “Nitrous Outlet” standalone fuel cell (More info and pics HERE)

Wheels/Tires

  • Steeda Hexentric 16×8.5″ Wheels
  • 245/45 ZR BFG Comp T/A’s (front)
  • M/T 255/50 16″ Et Street Radials (Drag Radials) (rear)
